Atrie G.SHDSL LAN Extender
High-Speed Symmetrical LAN Connectivity over Copper
Atrie WS3000 G.SHDSL LAN Extender provides reliable and cost-effective broadband connectivity over existing copper infrastructure. It enables symmetrical data transmission between two LAN locations using 1-pair/2-wire or 2-pair/4-wire copper, supporting data rates from 64/192/256 Kbps up to 15 Mbps over 2-wire and up to 30 Mbps over 4-wire, with higher-speed 60 Mbps 8-wire-pair operation available as an option.
Compliant with ITU-T G.991.2 G.SHDSL standards, WS3000 can operate as either STU-C (Central) or STU-R (Remote). It supports ATM/EFM over SHDSL, transparent Ethernet bridging, VLAN, routing, NAT, and comprehensive Web, Telnet and SNMP-based management.
Features
- ITU-T G.991.2 Compliant – Supports G.SHDSL with Annex A, B, F and G.
- Symmetrical Data Transmission – 64/192/256 Kbps up to 15 Mbps over 2-wire and up to 30 Mbps over 4-wire.
- Optional 60 Mbps Support – Higher bandwidth operation over 8-wire-pair copper.
- 1-Pair / 2-Pair Operation – Flexible copper deployment for different bandwidth requirements.
- STU-C / STU-R Selectable – Configurable for central or remote-side operation.
- TC-PAM Line Coding – Supports TC-PAM 16/32/64/128.
- ATM & EFM Support – Supports ATM/EFM over SHDSL.
- 4-Port Ethernet LAN – Four 10/100 Mbps RJ45 Ethernet interfaces.
- Transparent Ethernet Bridge – IEEE 802.1D transparent learning bridge.
- Routing & NAT – Supports static routing, RIPv1/RIPv2 and NAT functionality.
- VLAN Support – IEEE 802.1Q with up to 4094 VLAN IDs.
- Auto-Negotiation & Auto-MDIX – Simplifies Ethernet connectivity and deployment.
- Advanced Management – Web GUI, CLI, Telnet and SNMPv1/v2c/v3.
- Local Console – Convenient configuration and monitoring through console interface.
- DHCP & Ping Utility – Integrated network configuration and diagnostic tools.
- Surge Protection – Compliant with ITU-T K.20/K.21 protection requirements.
Advantages
- High-Speed Copper Connectivity: Provides broadband LAN connectivity over existing copper telephone infrastructure without requiring new fiber deployment.
- Symmetrical Bandwidth:-Supports symmetrical downstream and upstream data rates, making it suitable for business and LAN-to-LAN applications.
- Flexible Deployment: Supports 2-wire and 4-wire copper configurations, allowing network operators to select the required bandwidth based on available infrastructure.
- Multiple Network Services: Supports Ethernet bridging, routing, NAT, ATM and EFM for flexible network deployment.
- Extended Infrastructure Life: Enables organizations to utilize existing copper networks while providing higher-speed data connectivity.
- Easy Management:Web, Telnet, CLI and SNMP management simplify configuration, monitoring and troubleshooting.
- Reliable Network Protection:Built-in protection features support deployment in telecom and access network environments.
- Cost-Effective Network Extension:Provides an economical alternative for extending Ethernet connectivity where fiber infrastructure is not readily available.
- Firmware Upgrade – Software enhancement through HTTP-based upgrade.
- Performance Monitoring – SNR and attenuation value calculation.
